EASY TO USE
- Installed with pfSense software, ready to use immediately.
- Small and compact so it fits anywhere.
- Easy GUI management. Manage pfSense settings via the web.
- Complete firewall appliance solution
LOW TOTAL COST OF OWNERSHIP
- There are no locks or add-ons needed to make the system fully functional.
- No additional usage or resource-based pricing. There are no predefined limits on users, firewall rules, or IPsec tunnels.
- Low energy consumption to save money and be more sustainable.
ADVANTAGES OF APPLIANCE FIREWALL
- Flexible configuration and support for VPN, load balancing, reporting and monitoring.
- Simple package management system for adding powerful functions and features.
SECURE REMOTE ACCESS (VPN)
- Connect via encrypted VPN (Virtual Private Networks) between offices, allow mobile workers to connect securely, or connect to the cloud!
- Use OpenVPN to easily establish VPN connections with other company units.
COMMON USE CASES
- SMB for mid-sized networks
- Small to Medium Branch
- On-Premises Managed Service Provider (MSP) / Managed Security Service Provider (MSSP)
- High-Speed Home or Business Gigabit Connections
- Multiple VPN Connections
SOFTWARE FEATURES
The pfSense firewall appliance is a free, open source firewall and router distribution based on FreeBSD that is functionally competitive with expensive, proprietary commercial firewalls. pfSense software-based appliances can be configured as a stateful packet filtering firewall, a LAN or WAN router, VPN Appliance, DHCP Server, DNS Server, pfSense with Active Directory authentication, or can be configured for other applications and special-purpose devices. Features of this next-generation pfSense security appliance include:
- Stateful packet filtering firewall or pure router
- Per-gateway and per-rule routing policy for failover and load balancing
- Layer 2 Firewall
- Support for IPV6, NAT, BGP
- Captive portal with MAC filtering, RADIUS support, etc.
- VPN: IPsec, OpenVPN, L2TP
- Dynamic DNS client
- Reporting and resource monitoring with real-time information
TECHNICAL SPECIFICATIONS
| CPU | Intel Celeron J1800 2.58 GHz |
|---|---|
| CPU Cores | 2 |
| Memory Options | 2GB DDR3L 1333MHz 1.3v SO-DIMM expandable up to 8GB |
| Storage options | 32GB mSATA v3.0 SSD expandable up to 240GB MINI-PCI-E 6GB/S |
| Network Interfaces | 4x GbE RJ45 Intel 82583 v/i211-AT |
| Recommended users | 10 – 50 |
| USB ports | 2X 2.0 1X 3.0 |
| Console port | RJ45 |
| VGA | 1 Integrated Intel HD Graphics |
| Energy | Input: 1 inner diameter 2.5mm, outer diameter 5.5mm 100-240V, 50-60Hz, 60W AC Input: IEC320-C13 (2 PIN) Output: 12V 5A Power cord included |
| Chassi | Metal |
| Dimensions | 15 x 12,3 x 3,3 cm |
| Cooling | Passive (no fan needed) |
| Operating temperature | -10ºC – 60ºC |
| Hardware Warranty | 6 Months |
| Certifications | RoHS, CE |
| Energy consumption | 10W (idle) |
| Weight | 600 grams |
