EASY TO USE
- Installed with pfSense software, ready to use immediately.
- Small and compact so it fits anywhere.
- Easy GUI management. Manage pfSense settings via the web.
LOW TOTAL COST OF OWNERSHIP
- There are no locks or add-ons needed to make the system fully functional.
- No additional usage or resource-based pricing. There are no predefined limits on users, firewall rules, or IPsec tunnels.
- Low energy consumption to save money and be more sustainable.
GROWS WITH YOU
- Flexible configuration and support for VPN, load balancing, reporting and monitoring.
- Simple package management system for adding powerful functions and features.
SECURE REMOTE ACCESS
- Connect via encrypted VPN (Virtual Private Networks) between offices, allow mobile workers to connect securely, or connect to the cloud!
- Use OpenVPN to easily establish VPN connections with other company units.
COMMON USE CASES
- SMB for mid-sized networks
- Small to Medium Branch
- On-Premises Managed Service Provider (MSP) / Managed Security Service Provider (MSSP)
- High-Speed Home or Business Gigabit Connections
- Multiple VPN Connections
SOFTWARE FEATURES
pfSense software is a free, open source firewall and router distribution based on FreeBSD that is functionally competitive with expensive, proprietary commercial firewalls. pfSense software-based appliances can be configured as a stateful packet filtering firewall, a LAN or WAN router, VPN Appliance, DHCP Server, DNS Server, or can be configured for other applications and special-purpose devices. Features of this next-generation pfSense security appliance include:
- Stateful packet filtering firewall or pure router
- Per-gateway and per-rule routing policy for failover and load balancing
- Layer 2 Firewall
- Support for IPV6, NAT, BGP
- Captive portal with MAC filtering, RADIUS support, etc.
- VPN: IPsec, OpenVPN, L2TP
- Dynamic DNS client
- Reporting and resource monitoring with real-time information
TECHNICAL SPECIFICATIONS
| CPU | Intel i5 1235U Ten Cores, 12MB cache, 4.7 GHz |
|---|---|
| CPU Cores | 10 |
| Memory Options | 2x SO-DIMM DDR4-3200, Up to 64GB |
| Storage options | 1x mSATA up to 2TB, 1*2.5″ HDD |
| Network Interfaces | 6x Gigabit Ethernet RJ45 Intel 2.5GB LAN i225 |
| Wireless Wi-Fi | Does not have |
| USB ports | 3x USB 3.1 – 3x USB 2.0 |
| Console port | RJ45 |
| HDMI | 1x HDMI 1xDP |
| Energy | Input: 1 inner diameter 2.5mm, outer diameter 5.5mm 100-240V, 50-60Hz. AC Input: IEC320-C13 (2 PIN) Output: 12V 4A Power cord included |
| Chassi | Metal |
| Dimensions | 15.5X12.6X5.25 cm |
| Cooling | Passive (no fan needed) |
| Operating temperature | -10ºC – 60ºC |
| Hardware Warranty | 6 Months |
| Certifications | RoHS, CE |
| Energy consumption | 20W (max) |
| Weight | 1.3 KG |
